Specification Summary
- Probe type: construction with parallel sheath
- not bendable over first 50 mm from tip
- Temperature range: -50 to +300°C
- Element type: Pt100, single
- Resistance values and tolerances: IEC 60751 class B
- Recommended maximum current: 5 mA
- Minimum insulation resistance: 10 Mohm at ambient temperature with 200 V DC
- Wiring system: 3 or 4 wire from element
- Lead wire: Teflon insulated flexible copper wire
- Max. temperature limit lead wire: 200 °C
- Max. temperature transition: 200 °C
